SPECIFICATIONS
SPECIFICATIONS
- Engine type: 50cc, single cylinder,4-stroke,air-cooled, Auto.
- Bore X Stroke:39X41.4mm
- Compression Ratio: 9.0:1
- Max power:2.0kw/7500r/min +/-375r/min
- Min Fuel Consumption: <=367g/KW.H
- Max torquer:2.5N.m/ 5000r/min +/-250r/min
- lgnition mode: CDI
- Clutch: Auto
- Start: E-start
- Rear sprocket:14/37T, 420# Chains
- Frame: High strengthened steel
- Swing arm:Steel, A shape
- Suspension system :
- Front forks USD
- REAR Shock
- Brake system: Hydraulic disc brakes
- Maximum load: 75kgs
- Tank Capacity: 2.4 L
- G.W/N.W:70kgs/65kgs
- Carburetor: JINKE PZ19
- Dimensions(1400x750x900mm)
- Carton size: 1300mm*355mm*640mm
- Ground Clearance: 160mm
- Seat Height: 62cm
- Wheel base: 95cm
- Tire size:Front/Rear: 2.50-10 2.50-10
- Rim Size：Front 1.6-10/ Rear 1.6-10
